NOYAFA NF-811 RJ45 Network Cable Tester RJ11 Telephone Wire Tracker Toner Ethernet LAN Cable Detector Line Continuity Test Tool

Main functions:
1. tone trace the required line among numerous ones, perfect for tracking RJ11, RJ45, cables or other metal wire (via adapter)
2. It testes physical connection status of network cable, such as open circuit, short connection, miswire and reverse connection
3. Use the emitter to test the status of working of telephone lines, such as judging TIP or PING line and judging whether the telephone line is idle, ringing or off-hook
4. Highlights for 60V endurable, users can track wires which is in low-electricity less than 60V without burnout or damaged.
5. Clips allow easy access to individual pairs and RJ11 RJ45 easily connect to telephone jacks—no need for adapters
"6. Used on single conductors, twisted pairs, telephone cable and electrical wiring, a practical tool for service providers in network infrastructure installation, certification, and troubleshooting.

Technical indexes:
NF-811 Transmitter specification
Dual Tone frequency    0.6kHz    1.3kHz
Max. distance of transmission    2 kilometers
Max. working current    30mA
Compatible connectors    RJ11, RJ45
Max. signal voltage    8Vp-p
Function display    Led for Wiremap, Tone for trace
Voltage protection    DC 60V
Battery Type    DC9.0V（NEDA 1604/6F22 ) x1pc
Dimension(LxWxD)    130*47*35mm
NF-811 Receiver specification
 Tone frequency    0.6~1.3kHz
The Max. working current    90mA
Earphone jack    1
Battery Type    DC9.0V（NEDA 1604/6F22 ) x1pc
Dimension(LxWxD)    180*45*30mm

Accessories Included:
Tone Generator      x 1pcs
Amplifier probe    x 1pcs
User Manual       x 1pcs
9V battery      x 2pcs
Earphone      x 1pcs
Carry bag    x 1pcs
Gift box    x 1pcs
